Infusomat Compact Plus

Braun compactplus is the new generation of infusion pump, offering a large colour display, guided loading, novel intuitive user interface, integrated DoseGuard™drug library, and Li-Ion battery. The compactplus integrates the latest technological advances whilst maintaining simplicity and reliability through maintaining the proven robustness of the original compact pump range.

Infusomat Compact Plus

Product Details

Features

High resolution colour display
- Visibility from all angles
- Colour coded drug library
Intuitve user interface due to self explanatory menu
Integrated power supply for use with standard power cords
Integrated pole clamp and handle
Easy to use disposables with colour coded connectors
Lithium-Ion-battery
- Extended battery life with highly reliable Lithium-Ion batteries
- Recharging time only 3h
Protection against fluid ingress IP34

Technical Specifications

Model Name/Number	Infusomat Compact Plus
Weight	1.9 Kg
Syringe Size	: 2/3, 5, 10, 20, 30, 50/60 ml
Accuracy	+- 2% in compliance with IEC/EN 60601-2-24
Brand	B Braun
Display Type	Colour active matrix 2.4″ TFT, 240 x 320 pixels, 262k colours, viewing angle: all 80 Degree
Voltage	240 V
Is It Portable	Portable
Battery Type	Rechargeable Li-Ion battery Operating time: approx. 10h at 5 ml/h Recharging time: approx. 3h
Code No. (REF)	8717030
Dimensions (W x H x D)	290x 98x 220 mm
Moisture	IP34 (water splashing from any direction)
